A development of
our drums for those that require a larger capacity these pressure
vessels have been developed to meet the requirements of Packing
Instruction P601 and other requirements of IMDG/ADR for the transport
of bromine.
100 - 350 Litre
Vessels
Operating Pressure:
6.67 Barg
Hydraulic Test Pressure:
10 Barg
Design Code:
ASME VIII
Lining:
5 mm homogeneous lead to BS334 Chemical
Type A or B or 5 mm PVDF sheet
Valves:
DN25 (1" NB) lined diaphragm or ball
valves flanged 1" NB ASA150
Upto 150 ltrs 2 or 3 valves fitted.
Over 150 ltrs 2 valves maximum.
